Specifications
Components
-
Frame
Mako 4 EVO, XCO Geometry BGC, 113mm travel with integrated IN-LINK suspension, Full carbon HM2X, monocoque, bearings full ball ISB VMAX, BB92 bottom bracket, full internal cable system ICS2, MTB Acros Headset ZS56 with Blocklock 150º, Post Mount 160mm, 29x2.40" maximum tyre, BOOST Thru axle 12x148, UDH standard
-
Fork
FOX 34 SC Factory, Kashima Coat, FIT4, Remote Lockout 3 Position, Float Evol Air, Reb. Adj., 15x110mm Kabolt axle, Rake 44mm, Tapered steerer, 110mm travel
-
Material
Full carbon fiber HM2X
-
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, width: 740mm
-
Seatpost
TRANZX JD-YSPJL Aluminum 7075-T6, 0 offset, Ø31,6, 100mm travel
-
Saddle
Fizik Terra Ridon X5, Steel rails, length: 255mm, width: 145mm
-
Seat clamp
Universal Derailleur Hanger
-
Wheels
DT Swiss X1900 Spline 29", 15x110, Boost 12x148mm, TLR, XD Rear Hub, Center Lock, internal width 25mm
-
Control Changes
EC AXS POD Right Bridge W/MMX
-
Gear Changes
SRAM S1000 AXS Eagle T-TYPE, 12s
-
Cranks
SRAM S1000 T-TYPE, 34T, 170-175mm
-
Chain
SRAM EAGLE 70 T-TYPE, 120 Links
-
Cassette
CS XS1275 Eagle, T-TYPE, 10-52T
-
BB (Bottom Bracket)
SRAM DUB Wide PF92 MTB
-
Brake
SRAM Level Bronze Stealth, 4 Piston
-
