Specifications
Components
-
Frame
Bravo 6, XCO WC Racing Geometry BGC with 28mm travel SOFTEX Suspension System, Full carbon HM2X, Triple monocoque, BB92 Bottom bracket, Full internal cable system ICS2, MTB Acros Headset ZS56 with Blocklock 150º, Post Mount 160mm, 29x2.40" max. tyre, BOOST Thru axle 12x148mm, UDH standard
-
Fork
RockShox SID BSE, Damper Charger RL, Remote Lockout 3 Position, 15x110 Maxle Stealth, Tapered steerer, Spring Debon Air, Rake 44mm, 35mm tapered wall aluminum, Diffusion Black, 110mm travel
-
Material
Full carbon fiber HM2X
-
Handlebar
Avanforce AF3, Aluminum 6061, Ø31,8mm, width: 740mm
-
Seatpost
Avanforce Tibia, Softex Seat post, UD Carbon, 0 offset, Ø27,2, length: 300, 350, 420mm
-
Saddle
SRX Open Cut Athletic, Steel rails, length: 260mm, width: 148mm
-
Seat clamp
Universal Derailleur Hanger
-
Wheels
DT Swiss X1900 Spline 29", 15x110, Boost 12x148mm, TLR, XD Rear Hub, Center Lock, internal width 25mm
-
Control Changes
EC AXS POD Right Bridge W/MMX
-
Gear Changes
SRAM S1000 AXS Eagle T-TYPE, 12s
-
Cranks
SRAM S1000 T-TYPE, 34T, 170-175mm
-
Chain
SRAM EAGLE 70 T-TYPE, 120 Links
-
Cassette
CS XS1275 Eagle, T-TYPE, 10-52T
-
BB (Bottom Bracket)
SRAM DUB PF92 MTB
-
Brake
SRAM Level Black, 2 Piston
-
*We reserve the right to modify the information and components of the products that appear on this website without prior notice, including equipment, specifications, models, colors and materials.
